Stainless Steel Ball Valve

Name: Stainless Steel Ball Valve
Brand: Euro Flow Control
SKU: EFC-306
Availability: InStock

Debug · supplier source (internal only)

Supplier product page ↗EFC datasheet PDF ↗supplier: watts · ref: 306

Specifications

Confirmed at quote

Size Range: DN15-DN200
Pressure Class: PN16/PN25
Standards: ANSI B16.10, BS5152, API609, BS5155, DIN3202, ISO5752, JIS Mounting, ISO5211, ANSI 150LB/300LB, API 598

Available sizes

Standard DN sizes covered by this product. Confirmed at quote.

DN15 DN20 DN25 DN32 DN40 DN50 DN65 DN80 DN100 DN125 DN150 DN200

Available pressure classes

Pressure classes this product is rated to.

PN16 PN25

Configure your variant(manually adjust box on the right if you require a different spec)

Size
Pressure
End connection

Materials

All available material options per part. Click a pill to set it in the configurator.

body
bonnet
disc
ball
seat
stem
wrench

Dimensions per size(12 sizes)

Size	L	H	D	D1	n-d	Weight
DN15	115 mm	59 mm	95 mm	65 mm	4-15 mm	—
DN20	120 mm	63 mm	105 mm	75 mm	4-15 mm	—
DN25	125 mm	75 mm	115 mm	85 mm	4-15 mm	—
DN32	130 mm	86 mm	140 mm	100 mm	4-19 mm	—
DN40	140 mm	105 mm	150 mm	110 mm	4-19 mm	—
DN50	150 mm	115 mm	165 mm	125 mm	4-19 mm	—
DN65	170 mm	135 mm	185 mm	145 mm	4-19 mm	—
DN80	180 mm	155 mm	200 mm	160 mm	8-19 mm	—
DN100	190 mm	170 mm	220 mm	180 mm	8-19 mm	—
DN125	325 mm	195 mm	250 mm	210 mm	8-19 mm	—
DN150	350 mm	240 mm	285 mm	240 mm	8-23 mm	—
DN200	400 mm	295 mm	340 mm	295 mm	12-23 mm	—

Operating media

WaterOilGasAcidSteam

Actuation options

manual leveractuated

Approvals

Lloyd's Register (LR)ISOEACCEBureau VeritasACS (Attestation de Conformité Sanitaire)WRAS Approved ProductECM (Ente Certificazione Macchine)

Features

Blow-out proof stem
Investment casting body
Pressure balance hole in ball slot
Full bore
Threaded end types available: NPT, PT, BSP, BSPP, BSPT, DIN, Rc, Rp
Locking device available
Quarter-turn operation
Two-piece and three-piece body styles available
2-piece flanged ball valve construction
Full bore (full port) design
Lever operated with lockable handle
Raised face flanges
Stem with blue packing gland adjustment nut
Body cast material marked CF8 (equivalent to 304 stainless steel casting grade)
Bolted body joint (split body)
Drain/blowdown plug fitted to lower body (item 6)

Notes

Threaded type: NPT, PT, BSP, BSPP, BSPT, DIN, Rc, Rp is available
Locking device is available
Diagram: Sectional cross-section drawing of a 2-piece flanged ball valve showing 6 numbered part callouts (1: stem/handle assembly, 2: stem packing/gland area, 3: seat/seat retainer, 4: ball, 5: body lower half, 6: drain plug/blowdown fitting) with key dimensional references annotated: L (face-to-face length), H (overall height including handle), D (flange outside diameter), D1 (bolt circle diameter), DN (nominal bore), n-d (number and diameter of flange bolt holes)

Description

A flanged stainless steel ball valve with investment-cast body available in CF8, CF8M, CF3, and CF3M grades. Operates via a quarter-turn mechanism with full bore design and PTFE or RPTFE seats. Rated to PN16/25 and ANSI 150LB/300LB, suitable for working temperatures from -20 °C to 425 °C with media including water, oil, gas, acid, and steam.
