P20A Differential Pressure Pilot
Debug Β· supplier source (internal only)
Dimensions per size(16 sizes)
| Size | L | Weight |
|---|---|---|
| DN50 | 230 mm | β |
| DN65 | 290 mm | β |
| DN80 | 310 mm | β |
| DN100 | 350 mm | β |
| DN125 | 400 mm | β |
| DN150 | 480 mm | β |
| DN200 | 600 mm | β |
| DN250 | 730 mm | β |
| DN300 | 850 mm | β |
| DN350 | 980 mm | β |
| DN400 | 1100 mm | β |
| DN450 | 1200 mm | β |
| DN500 | 1250 mm | β |
| DN600 | 1450 mm | β |
| DN700 | 1650 mm | β |
| DN800 | 1850 mm | β |
Approvals
Features
- The P20A differential pressure pilot senses the pressure drop across an orifice or meter in the main pipeline and sends a hydraulic signal to the control valve to maintain a constant differential pressure
- Used on A400 flow control valves and energy management applications where a fixed differential pressure must be maintained across metering sections or heat exchangers
Description
Differential pressure sensing pilot for flow control. The P20A differential pressure pilot senses the pressure drop across an orifice or meter in the main pipeline and sends a hydraulic signal to the control valve to maintain a constant differential pressure. Used on A400 flow control valves and energy management applications where a fixed differential pressure must be maintained across metering sections or heat exchangers.
