Ductile Iron Basket Strainer
Debug · supplier source (internal only)
Specifications
Confirmed at quote- Size Range
- DN25-DN400
- Pressure Class
- PN10/PN25
- Standards
- ANSI B16.10, BS5152, ANSI/EN1092.2, DIN EN12266
Available sizes
Standard DN sizes covered by this product. Confirmed at quote.
Available pressure classes
Pressure classes this product is rated to.
Configure your variant(manually adjust box on the right if you require a different spec)
- Size
- Pressure
- End connection
Materials
All available material options per part. Click a pill to set it in the configurator.
- body
- bonnet
- Body
- Bolt
- Bolt nut
- cover
- Cover
- Cover gasket
- cover bolts and nuts
- cover gasket
- drain plug
- filter
- Plug
- Screen
Operating media
Approvals
Features
- Large-capacity basket screen for particle trapping with continuous flow
- Removable cover for maintenance access
- Internal basket design for reduced system downtime
- Flanged body with liquid painting or epoxy coating for corrosion resistance
- Nominal pressure: 200 Psi
- Suitable medium: water
- Shell test pressure: 300 Psi
- Seat test pressure: 200 Psi
- Working temperature: -20°C to 80°C
- Y-pattern strainer body with flanged ends
- Removable screen element (item 2)
- Flanged cover with gasket for screen access
- Body casting marked DN150 PN16 GGG50 (visible on product photo)
Notes
- Body with Liquid panting or Epoxy Coating.
- Operator field left blank in product table.
- Diagram: Sectional/dimensional drawing of a Y-type flanged strainer showing cross-section with numbered parts (1 Body, 2 Screen, 3 Cover gasket, 4 Cover, 5 Bolt, 6 Bolt nut, 7 Plug), dimension references L, D, K, G, B, f, H1, H2, and associated dimension table covering DN40–DN600 with standards notes.
Description
Ductile Iron Basket Strainer Facebook Twitter LinkedIn Ductile Iron Basket Strainer Class: PN10 / 16 / 25 Flange: ANSI/EN1092.2 Testing: DIN EN12266 Size: DN25-DN400 Send Quality Assurance We have a dedicated quality control team and advanced testing equipment to ensure consistent product quality. Timely Delivery With reliable raw material suppliers and streamlined production processes, we guarantee on-time delivery. Excellent After-Sales Service Our team of valve experts provide impeccable after-sales support Certifications Our products hold up to 10 international authoritative certification certificates, ensuring compliance with global standards. 联系方式 [email protected] +86 18698064661 Description Product Description The Ductile Iron Basket Strainer is a heavy-duty filtration device desig
